Teco-Westinghouse Max-PE Electric Motors



MAX-PE Rigid Base & C-Face TEFC Motors

HP
RPM
    • Three Phase, 60 Hz, 1.15 Service Factor (Continuous); 50 Hz, 1.0 Service Factor (Continuous)
    • CSA Certified for Class I, Div. 2, Groups B, C, D - Temp Code T3C Minimum
    • Class F Insulation
    • Class B Temperature Rise
    • NEMA Design B Torques as a Minimum; Various Ratings also Meet Design C
    • Cast Iron Frame and End Brackets; Rolled Steel Fan Cover and Main Conduit Box
    • Grounding Terminal Inside Main Conduit Box
    • Oversized Main Conduit Box Rotatable in 90 Degree Increments - F1 Mounted
    • Designed for 40˚C Ambient Temperature
    • Designed for 3300 ft. Elevation
    • Bi-Directional Rotation
    • 1045 Carbon Steel Shaft
    • Aluminum Die Cast Squirrel Cage Rotor Construction
    • Paint System: Phenolic Rust Proof Base Plus Polyurethane Top Coat
    • Paint Color: Dark Gray - Munsell 7.5B 3.5/0.5
    • Double Shielded Bearings Pre-Packed with MULTEMP SRL for F# 140T - 280T (Non-regreasable)
    • High Quality Ball (or Roller) Bearings Regreasable with Mobil Polyrex™ EM for F# 280TS and Larger
    • Automatic Grease Discharge Fittings on Regreasable Models
    • Labyrinth Type Metal Flinger on Both Ends for F# 280TS and Larger
    • Cast Iron Inner and Outer Bearing Caps for F#280TS and Larger
    • Stainless Steel Nameplate
    • New Dual Column Design Nameplate as Standard (60/50 Hz)
    • Suitable for Inverter Use per NEMA MG-1.4.4.2, Part 31
    • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
    • 9 Leads for 5 HP and Smaller;
    • 12 Leads for 7.5 HP to 125 HP;
    • 6 Leads for 150 HP and Larger
    • Motors are U.L. Recognized, CSA Approved and CE Marked
    • Dual Drilled Feet Available on Most Ratings - Longer Frames (i.e. 145T Drilled also for 143T)
    • Provisions for Breather Drains for Vertical Mount Down (F# 324T and Larger)
    • Rubber Dust Flinger on Drive-End for F# 140T - 280T
